| PartNumber | LM230WF9-SSA1 |
| Brand | LG Display |
| Size | 23.0 |
| Application | Desktop Monitor |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | LM230WF9-SSA1 |
| Diagonal Size | 23.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 95PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 509.184(H)×286.416(V) mm |
| Outline Dim. | 516.984(H)×302.708(V) ×14.2(D) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED [14S4P] , 30K hours , W/O Driver |
| Weight | 1.79/1.88Kgs (Typ./Max.) |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
