| PartNumber | LM240WU2-SLB4 |
| Brand | LG Display |
| Size | 24.0 |
| Application | DMPC |
| Resolution | 1920(RGB)×1200 , WUXGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | LG.Philips LCD |
| Panel Model | LM240WU2-SLB4 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 24.0 inch |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Active Area | 518.4×324 mm |
| Outline | 546.4×350 mm |
| Surface | Glare (Haze 0%), Hard coating (2H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 5.5/6.5 (Typ.)(Tr/Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 14 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
