| PartNumber | LMS500HF05 |
| Brand | Samsung |
| Size | 5.0 |
| Application | PND |
| Resolution | 480×272(RGB) , WQVGA |
| Composition | LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SAMSUNG SMD |
| Panel Model | LMS500HF05 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.0 inch |
| Display Mode | VA, Normally Black, TMR |
| Active Area | 110.88×62.832 mm |
| Surface | |
| Contrast Ratio | 800 : 1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 17/15 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLED |
| Signal Interface | Parallel RGB (1 ch, 8-bit) |
| Input Voltage | 3.3V (Typ.) |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| LMS500HF01 | Samsung | 5.0 | 480×272 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LMS500HF13-002 | Samsung | 5.0 | 480×272 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| PD050VX2 | E Ink | 5.0 | 480×640 |
| 43WQW4H | SII | 4.3 | 480×272 |
| LMS430HF26 | Samsung | 4.3 | 480×272 |
| LMS430HF27 | Samsung | 4.3 | 480×272 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
