| PartNumber | LP116WH8-SPA1 |
| Brand | LG Display |
| Size | 11.6 |
| Application | Laptop |
| Resolution | 1366×768 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 262K |
| Backlight | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Manufacturer | LG Display |
| Model Name | LP116WH8-SPA1 (LGD0500) |
| Screen Size | 11.6 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1366(RGB)×768 (WXGA) 135PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 256.125 × 144 (H×V) |
| Outline(mm) | 278 × 168 × 3.2 (H×V×D) |
| Bezel Area(mm) | 260.15 × 147.5 (H×V) |
| Treatment | Glare (Haze 0%) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 35 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 262K 48% NTSC |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | In-Cell Touch |
| Signal Type | eDP (1 Lane) , HBR1 (2.7G/lane) , Connector 40 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
