PartNumber | LP133WF4-SPB1 |
Brand | LG Display |
Size | 13.3 |
Application | Laptop |
Resolution | 1920×1080 |
Composition | LCM , a-Si TFT-LCD |
Brightness | |
CR | 700:1 |
Colors | 262K |
Backlight | WLED , 15K hours , With LED Driver |
Interface | |
Manufacturer | LG Display |
Screen Size | 13.3 inch |
Pixel Number | 1920(RGB)×1080 (FHD) 166PPI |
Active Area(mm) | 293.76 × 165.24 (H×V) |
Bezel Area(mm) | - |
Luminance | 300 (Typ.)(cd/m²) |
Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
Good View at | Symmetry |
Color Depth | 262K 72% NTSC |
Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
Refresh Rate | 60Hz |
Model Name | LP133WF4-SPB1 (LGD04EF) |
Screen Type | LCM , a-Si TFT-LCD |
Arrangement | RGB Vertical Stripe |
Outline(mm) | 300.26 × 188.75 × 2.5 (H×V×D) |
Treatment | Antiglare |
Contrast Ratio | 700 : 1 (Typ.) (TM) |
Work Mode | IPS, Normally Black, Transmissive |
Response | 25 (Typ.)(Tr+Td) ms |
Used for | Laptop |
Touchscreen | Without |
LP133WD1-SLA1 | LG Display | 13.3 | 1600×900 |
LP133WF6-SSA1 | LG Display | 13.3 | 1920×1080 |
LP133WH2-TLA3 | LG Display | 13.3 | 1366×768 |
LP133WH2-TLL1 | LG Display | 13.3 | 1366×768 |
LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
LP133WX1-TLA1 | LG Display | 13.3 | 1280×800 |
LP133WX1-TLN2 | LG Display | 13.3 | 1280×800 |
LP133WX2-TLA2 | LG Display | 13.3 | 1280×800 |
LP133WX3-TLA1 | LG Display | 13.3 | 1280×800 |
