| PartNumber | LP140WH6-TJA1 |
| Brand | LG Display |
| Size | 14.0 |
| Application | NBPC |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 500:1 |
| Colors | 262K |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LP140WH6-TJA1 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 14.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 309.399×173.952 mm |
| Outline | 322.3×198.68 mm |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 6.1% (Typ.)(with Polarizer) |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193145% |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/15/35 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
