| PartNumber | LTN141XB-L04 |
| Brand | Samsung |
| Size | 14.1 |
| Application | NBPC |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 185 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTN141XB-L04 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 14.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 285.696×214.272 mm |
| Outline | 299×240.6×5.5 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 300:1 (Min.) |
| Display Colors | 262K (6-bit) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| LTN141AT05-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
| LTN141AT06-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT15-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN141BT06-002 | Samsung | 14.1 | 1440×900 |
| LTN141BT08-001 | Samsung | 14.1 | 1440×900 |
| LTN141W1-L09 | Samsung | 14.1 | 1280×800 |
| LTN141XB-L04 | Samsung | 14.1 | 1024×768 |
| B133XTN01.2 | AUO | 13.3 | 1366×768 |
| B140XW01 V0 | AUO | 14.0 | 1366×768 |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| HSD173PUW1-A | HannStar | 17.3 | 1920×1080 |
| LM-DA53-22NTW | SANYO | 8.0 | 640×480 |
| LP129QE1-SPA1 | LG Display | 12.9 | 2560×1700 |
| LP150X08-TLAD | LG Display | 15.0 | 1024×768 |
| LP156WD1-TLD3 | LG Display | 15.6 | 1600×900 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
