| PartNumber | LP141WP1-TLC3 |
| Brand | LG Display |
| Size | 14.1 |
| Application | NBPC |
| Resolution | 1440(RGB)×900 , WXGA+ |
| Composition | LCM |
| Brightness | 235 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | LG.Philips LCD |
| Panel Model | LP141WP1-TLC3 12 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 14.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 303.69×189.81 mm |
| Outline | 319.5×205.5×5.5 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare |
| Contrast Ratio | 300:1 (Min.) |
| Display Colors | 262K (6-bit) |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/15/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| LP141WP1-TLA2 | LG Display | 14.1 | 1440×900 |
| LP141WP1-TLA3 | LG Display | 14.1 | 1440×900 |
| LP141WP1-TLC1 | LG Display | 14.1 | 1440×900 |
| LP141WP2-TLB1 | LG Display | 14.1 | 1440×900 |
| LP141WP3-TLA1 | LG Display | 14.1 | 1440×900 |
| LP141WX3-TLA3 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLB1 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLN1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLP1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLP2 | LG Display | 14.1 | 1280×800 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| B140QAN01.0 | AUO | 14.0 | 2560×1440 |
| B154EW09 V2 | AUO | 15.4 | 1280×800 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| LP154W01-TLAD | LG Display | 15.4 | 1280×800 |
| LP156WD1-TLD5 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLA1 | LG Display | 15.6 | 1920×1080 |
| LTN121W1-L03 | Samsung | 12.1 | 1280×800 |
| LTN133HL01-301 | Samsung | 13.3 | 1920×1080 |
| N121IB-L04 | Innolux | 12.1 | 1280×800 |
