| PartNumber | B140QAN01.0 |
| Brand | AUO |
| Size | 14.0 |
| Application | NBPC |
| Resolution | 2560(RGB)×1440 , Quad-HD |
| Composition | LCM |
| Brightness | 340 cd/m² (Typ.) |
| CR | 700:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | AUO |
| Panel Model | B140QAN01.0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 14.0 inch |
| Display Mode | AHVA, Normally Black, Transmissive |
| Active Area | 309.35×174.01 mm |
| Outline | 320.4×205.1×2.6 mm |
| Shape Style | Slim (PCBA Flat, Depth ≤3.2mm) |
| Surface | Hard coating (3H) |
| Contrast Ratio | 700:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 40 pins |
| Input Voltage | 3.3V (Typ.) |
