| PartNumber | LP141WX3-TLN4 |
| Brand | LG Display |
| Size | 14.1 |
| Application | NBPC |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LP141WX3-TLN4 18 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 14.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 303.74×189.84 mm |
| Outline | 319.5×205.5×5.5 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 300:1 (Min.) |
| Display Colors | 262K (6-bit) |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 40/40/15/35 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| LP141WP1-TLA3 | LG Display | 14.1 | 1440×900 |
| LP141WX1-TL01 | LG Display | 14.1 | 1280×800 |
| LP141WX1-TL02 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLA4 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLN1 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLN4 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLA1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLC1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLD1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLN1 | LG Display | 14.1 | 1280×800 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B133XTN01.6 HW1A | AUO | 13.3 | 1366×768 |
| CLAA154WB08AN | CPT | 15.4 | 1280×800 |
| LP133X7-F2IB | LG Display | 13.3 | 1024×768 |
| LP171WU6-TLB1 | LG Display | 17.1 | 1920×1200 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTN133YL01-L01 | Samsung | 13.3 | 3200×1800 |
| N133B6-L01 | Innolux | 13.3 | 1366×768 |
| N133I6-L10 | Innolux | 13.3 | 1280×800 |
| N173O6-L02 | Innolux | 17.3 | 1600×900 |
