| PartNumber | LP160WQ1-SPA1 |
| Brand | LG Display |
| Size | 16.0 |
| Application | Laptop Gaming |
| Resolution | 2560(RGB)×1600, WQXGA, 188PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1200:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | |
| Panel Brand | LG Display |
| Panel Size | 16.0" |
| Display Area | 344.678(W)×215.424(H) mm |
| Outline Size | 349.06(W)×229.39(H) ×3.8(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 1.07B 100% DCI-P3 |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Bent, T≤3.0mm) |
| Panel Model | LP160WQ1-SPA1 (LGD0694) |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Display Mode | IPS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
