| PartNumber | LTN160HT02-001 |
| Brand | Samsung |
| Size | 16.0 |
| Application | NBPC |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | RGB LED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTN160HT02-001 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 16.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 353.28×198.72 mm |
| Outline | 365×217 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare (Haze 40%), Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), Adobe100% |
| Response Time | 8 (Typ.)(Tr+Td) |
| Viewing Angle | 75/75/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | RGB LEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 6-bit), 50 pins |
| Input Voltage | 3.3V (Typ.) |
