| PartNumber | LPM035M407B |
| Brand | JDI |
| Size | 3.5 |
| Application | HMD VR AR |
| Resolution | 1440×1600 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Model | LPM035M407B |
| Diagonal Size | 3.5 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1440(RGB)×1600 615PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 59.4(H)×66(V) mm |
| Outline Dim. | 62.2(H)×73.6(V) mm |
| Bezel Area | - |
| Treatment | Hard coating |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M |
| Light Source | WLED [5S2P] |
| Weight | 17.0g (Typ.) |
| Designed For | HMD VR AR |
| Frame Rate | 90Hz |
| Touch Panel | Without |
| Interface Type | MIPI (4 data lanes) |
| Power Supply | 1.8/5.7/-5.7V (Typ.)(VDDI/AVDD/AVEE) |
| Environment | Operating Temperature: -10 ~ 55 °C ; Storage Temperature: -20 ~ 70 °C |
