| PartNumber | LQ035Q1DG01 |
| Brand | SHARP |
| Size | 3.5 |
| Application | |
| Resolution | 320(RGB)×240 , QVGA |
| Composition | LCM |
| Brightness | 340 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LQ035Q1DG01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 3.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 70.56×52.92 mm |
| Outline | 76.9×63.9×3.65 mm |
| Surface | |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 30/30 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 54 pins |
| Input Voltage | 3.3/3.3V (Typ.)(VDD/AVDD) |
