| PartNumber | LQ050A5AG03 |
| Brand | Sharp |
| Size | 5.0 |
| Application | Automotive Display |
| Resolution | 320×234 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 60:1 |
| Colors | Full |
| Backlight | 1 pcs CCFL , 10K hours , No Driver |
| Interface | Analog |
| Manufacturer | Sharp |
| Model Name | LQ050A5AG03 |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 320(RGB)×234 79PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 102.124 × 74.763 (H×V) |
| Outline(mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antireflection |
| Luminance | 320 cd/m² (Typ.) |
| Contrast Ratio | 60 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/40/65 (Typ.)(CR≥5) |
| Response | 30/50 (Typ.)(Tr/Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | Full color |
| Mass | 180g (Max.) |
| Used for | Automotive Display |
| Refresh Rate | - |
| Touchscreen | Without |
| Signal Type | Analog RGB , Connector 22 pins |
| Voltage Supply | 8.0/-5.0V (Typ.)(VSH/VSL) |
| Max. Ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
