| PartNumber | LQ080M1SX01 |
| Brand | Sharp |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 1200(RGB)×1920, WUXGA, 284PPI |
| Composition | Oxide TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | 5S5P |
| Interface | |
| Panel Brand | Sharp |
| Panel Size | 8.0" |
| Display Area | 107.28(W)×171.648(H) mm |
| Outline Size | 112.38(W)×182.75(H) ×3.19(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 90% NTSC |
| Frequency | 75Hz |
| Weight | 67g (Max.) |
| Panel Model | LQ080M1SX01 |
| Panel Type | Oxide TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Clear, Hard coating |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Display Mode | IPS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | 5S5P WLED , 15K hours , Without Driver |
| Touch Screen | Without |
