| PartNumber | LQ088H9DR01U |
| Brand | SHARP |
| Size | 8.8 |
| Application | CNS |
| Resolution | 640(RGB)×240 , HVGA |
| Composition | LCM |
| Brightness | 220 cd/m² (Typ.) |
| CR | |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LQ088H9DR01U |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.8 inch |
| Display Mode | TN, Normally White, Transflective |
| Active Area | 209.28×78.48 mm |
| Outline | 231.6×103.6 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 262K (6-bit) |
| Response Time | |
| Viewing Angle | |
| Lamp Type | 2 pcsCCFL |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| RoHS: |
