| PartNumber | LQ088H9DZ03 |
| Brand | SHARP |
| Size | 8.8 |
| Application | CNS |
| Resolution | 640(RGB)×240 , HVGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 180:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LQ088H9DZ03 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.8 inch |
| Display Mode | TN, Normally White, Transflective |
| Active Area | 209.28×78.48 mm |
| Outline | 231.6×103.3 mm |
| Surface | Antiglare |
| Contrast Ratio | 180:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| Display Colors | 262K (6-bit) |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 50/50/45/45 (Typ.)(CR≥15)(L/R/U/D) |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| Input Voltage | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
