| PartNumber | LQ133Z1JW04-E |
| Brand | Sharp |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 3200×1800 |
| Composition | LCM, Oxide TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Manufacturer | Sharp |
| Model Name | LQ133Z1JW04-E |
| Screen Size | 13.3 inch |
| Screen Type | LCM, Oxide TFT-LCD |
| Pixel Number | 3200(RGB)×1800 276PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 293.76 × 165.24 (H×V) |
| Outline(mm) | - |
| Luminance | - |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | VA, Normally Black, Transmissive |
| Color Depth | 16.7M |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (4 Lanes) , Connector 40 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -25 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
