| PartNumber | LQ231U1LW21 |
| Brand | SHARP |
| Size | 23.1 |
| Application | IA |
| Resolution | 1600(RGB)×1200 , UXGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | OpenLDI |
| Panel Brand | SHARP |
| Panel Model | LQ231U1LW21 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.1 inch |
| Display Mode | Transmissive |
| Active Area | 470.4×352.8 mm |
| Outline | 530×432.8 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 16.7M (8-bit) |
| Response Time | |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Lamp Type | 6 pcsCCFLEmbedded (Inverter) |
| Signal Interface | OpenLDI |
| RoHS: |
