| PartNumber | LQ231U1LW01 |
| Brand | SHARP |
| Size | 23.1 |
| Application | IA |
| Resolution | 1600(RGB)×1200 , UXGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | OpenLDI |
| Panel Brand | SHARP |
| Panel Model | LQ231U1LW01 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.1 inch |
| Display Mode | MVA, Normally Black, Transmissive |
| Active Area | 470.4×352.8 mm |
| Outline | 530×432.8×33.5 mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 20/10 (Typ.)(Tr/Td); 15 (Typ.)(G to G) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Lamp Type | 6 pcsCCFLEmbedded (Inverter) |
| Signal Interface | OpenLDI, 31 pins |
| Input Voltage | 5.0V (Typ.) |
