| PartNumber | T-55692D070H-LW-A-AAN |
| Brand | Kyocera |
| Size | 7.0 |
| Application | IA |
| Resolution | 800(RGB)×480 , WVGA |
| Composition | LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | OPTREX |
| Panel Model | T-55692D070H-LW-A-AAN 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 7.0 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 152.4×91.44 mm |
| Outline | 169.8×109.7×9.4 mm |
| Surface | Clear, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| Response Time | 12/12 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
