| PartNumber | LSC480HN08-8 |
| Brand | SAMSUNG |
| Size | 48 |
| Application | TV Sets |
| Resolution | 1920×1080 |
| Composition | CELL, a-Si TFT-LCD |
| Brightness | |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | LVDS |
| Manufacturer | SAMSUNG |
| Model Name | LSC480HN08-8 |
| Screen Size | 48 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 1920×1080(RGB) (FHD) 46PPI |
| Arrangement | RGB Horizontal Stripe |
| Active Area(mm) | 1054.08 × 592.92 (H×V) |
| Outline(mm) | 1068.08 × 608.92 × 1.3 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare, Hard coating (2H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 4000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | SVA, Normally Black, Transmissive |
| Glass Thickness | 0.40+0.50 mm |
| Transmissivity | 6.6% (Typ.)(with Polarizer) |
| Color Depth | 1.07B 68% NTSC |
| Mass | 2.80Kgs (Typ.) |
| Used for | TV Sets |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Driver IC list | Built-in COF 2 source chips |
| Signal Type | LVDS (2 ch, 10-bit) , Connector 51 pins |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
