| PartNumber | HV480FH2-600 |
| Brand | BOE |
| Size | 48 |
| Application | LCTV |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | HV480FH2-600 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 48 inch |
| Display Mode | ADS, Normally Black, Transmissive |
| Active Area | 1054.08×592.92 mm |
| Outline | 1064.1×605.4 mm |
| Surface | Antiglare (Haze 1%) |
| Transmissivity | 5.8% (Typ.)(with Polarizer) |
| Contrast Ratio | 1200:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (2 ch, 10-bit), 51 pins |
| Input Voltage | 12.0V (Typ.) |
