| PartNumber | LTA230A172F |
| Brand | TOSHIBA |
| Size | 23.0 |
| Application | LCTV |
| Resolution | 1280(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | Toshiba Matsushita |
| Panel Model | LTA230A172F |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.0 inch |
| Display Mode | OCB, Normally Black, Transmissive |
| Active Area | 501.12×300.67 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 16.7M (8-bit) |
| Response Time | 1/4 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | CCFL |
