| PartNumber | LTA320AP32 |
| Brand | Samsung |
| Size | 31.5 |
| Application | LCTV |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 4000:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTA320AP32 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 31.5 inch |
| Display Mode | PVA, Normally Black, Transmissive |
| Active Area | 697.685×392.256 mm |
| Outline | 760×450×46.8 mm |
| Surface | Antiglare (Haze 14%), Hard coating (3H) |
| Contrast Ratio | 4000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 20 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
| LTA320AP21 | Samsung | 31.5 | 1366×768 |
| LTA320AP27 | Samsung | 31.5 | 1366×768 |
| LTA320AP29-W | Samsung | 31.5 | 1366×768 |
| LTA320HA02 | Samsung | 31.5 | 1920×1080 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA320HJ03 | Samsung | 31.5 | 1920×1080 |
| LTA320HJ06 | Samsung | 31.5 | 1920×1080 |
| LTA320HN02-W | Samsung | 31.5 | 1920×1080 |
| LTA320W1-L02 | Samsung | 31.5 | 1280×768 |
| LTA320W2-L03 | Samsung | 31.5 | 1366×768 |
| LC320WX6-SLA3 | LG Display | 31.5 | 1366×768 |
| LC320WXN-SAA2 | LG Display | 31.5 | 1366×768 |
| LC420EUF-PFF1 | LG Display | 42 | 1920×1080 |
| LC550DUE-FGP2 | LG Display | 55 | 1920×1080 |
| LC550EUB-SCA1 | LG Display | 55 | 1920×1080 |
| LC550WUD-SBM3 | LG Display | 55 | 1920×1080 |
| LTA550HJ07 | Samsung | 55 | 1920×1080 |
| T370HW02 V9 | AUO | 37 | 1920×1080 |
| T546HW01 V0 | AUO | 55 | 1920×1080 |
| V420H2-L01 | Innolux | 42 | 1920×1080 |
