| PartNumber | LTL097QL01-W01 |
| Brand | Samsung |
| Size | 9.7 |
| Application | PAD |
| Resolution | 2048(RGB)×1536 , QXGA |
| Composition | LCM |
| Brightness | 420 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | SAMSUNG |
| Panel Model | LTL097QL01-W01 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 9.7 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 196.608×147.456 mm |
| Outline | 208.88×167.12×5.02 mm |
| Surface | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 51 pins |
| Input Voltage | 3.3V (Typ.) |
