| PartNumber | LP097QX3-SPAV |
| Brand | LG Display |
| Size | 9.7 |
| Application | PAD |
| Resolution | 1536(RGB)×2048 , QXGA |
| Composition | Assembly |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | LG Display |
| Panel Model | LP097QX3-SPAV |
| Panel Type | a-Si TFT-LCD , Assembly |
| Panel Size | 9.7 inch |
| Active Area | 147.456×196.608 mm |
| Outline | 167.094×237.618×5.3 mm |
| Surface | Glare (Haze 0%), Hard coating (3H), Antireflection |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193170% |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | eDP (4 Lanes), 60 pins |
| Input Voltage | 3.7V (Typ.) |
