| PartNumber | LP097QX1-SPA2 |
| Brand | LG Display |
| Size | 9.7 |
| Application | PAD |
| Resolution | 2048(RGB)×1536 , QXGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | LG Display |
| Panel Model | LP097QX1-SPA2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 9.7 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 196.608×147.456 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 16.7M (8-bit) |
| Response Time | 16 (Typ.)(G to G) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLED |
| Signal Interface | eDP (4 Lanes) |
