| PartNumber | LTL101DL03-T01 |
| Brand | Samsung |
| Size | 10.1 |
| Application | PAD |
| Resolution | 2560RG(BW)×1600 , WQXGA |
| Composition | LCM |
| Brightness | 370 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | SAMSUNG |
| Panel Model | LTL101DL03-T01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 216.576×135.36 mm |
| Outline | 232.22×156.92×5.2 mm |
| Surface | Glare (Haze 0%), Hard coating (2H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC) |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S6PWLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 45 pins |
| Input Voltage | 3.3V (Typ.) |
