| PartNumber | LTL101AL06-801 |
| Brand | Samsung |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTL101AL06-801 5 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 216.96×135.6 mm |
| Outline | 228.21×148.86×4.59 mm |
| Surface | Hard coating (3H) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC), CIE193150% |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 stringsWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 45 pins |
| Input Voltage | 3.3V (Typ.) |
