| PartNumber | LP125WH2-SLB1 |
| Brand | LG Display |
| Size | 12.5 |
| Application | PAD |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LP125WH2-SLB1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 12.5 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 275.59×154.94 mm |
| Outline | 300.4×180.9×3.7 mm |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Min.) |
| Display Colors | 262K (6-bit), CIE193150% |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| LP125WF1-SPA2 | LG Display | 12.5 | 1920×1080 |
| LP125WF1-SPA3 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB3 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| BF097XN | Innolux | 9.7 | 1024×768 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LP097X02-SLQE | LG Display | 9.7 | 1024×768 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTL097QL01-W01 | Samsung | 9.7 | 2048×1536 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
