| PartNumber | BF097XN |
| Brand | Innolux |
| Size | 9.7 |
| Application | PAD |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 420 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | CHIMEI INNOLUX |
| Panel Model | BF097XN |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 9.7 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 196.608×147.456 mm |
| Outline | 210×164.25×5.25 mm |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 20 (Typ.)(G to G); 20 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S6PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
