| PartNumber | LTM150XS-T01 |
| Brand | Samsung |
| Size | 15.0 |
| Application | DMPC |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | SAMSUNG |
| Panel Model | LTM150XS-T01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 304.128×228.096 mm |
| Outline | 331.3×257.9×16.4 mm |
| Surface | Antiglare (Haze 12%), Hard coating (3H) |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 10/35 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | TTL (2 ch, 6-bit), 55 pins |
| Input Voltage | 3.3V (Typ.)(VDD) |
