| PartNumber | LTM184HL01 |
| Brand | Samsung |
| Size | 18.4 |
| Application | DMPC |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTM184HL01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 18.4 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 408.96×230.04 mm |
| Outline | 443.4×266.5×4.3 mm |
| Surface | Antiglare (Haze 1%), Antireflection |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193172% |
| Response Time | 16 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 12S6PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Voltage | 5.0V (Typ.) |
