| PartNumber | LTM236FL01 |
| Brand | Samsung |
| Size | 23.6 |
| Application | DMPC |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | SAMSUNG |
| Panel Model | LTM236FL01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.6 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 521.28×293.22 mm |
| Outline | 544.8×320.5×11 mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), sRGB100% |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 stringsWLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 51 pins |
| Input Voltage | 5.0V (Typ.) |
