| PartNumber | LTN154U1-L02 |
| Brand | Samsung |
| Size | 15.4 |
| Application | NBPC |
| Resolution | 1920(RGB)×1200 , WUXGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | 262K |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTN154U1-L02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.4 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 331.2×207 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | |
| Contrast Ratio | |
| Display Colors | 262K (6-bit) |
| Response Time | |
| Viewing Angle | |
| Frequency | 60Hz |
| Lamp Type | CCFL |
| Signal Interface | LVDS (2 ch, 6-bit) |
| RoHS: |
| LTN154AT09-101 | Samsung | 15.4 | 1280×800 |
| LTN154BT05-D01 | Samsung | 15.4 | 1440×900 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| LTN154U1-L02 | Samsung | 15.4 | 1920×1200 |
| LTN154U2-L04-0 | Samsung | 15.4 | 1920×1200 |
| LTN154X1-L01 | Samsung | 15.4 | 1280×800 |
| LTN154X1-L03 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L09-G | Samsung | 15.4 | 1280×800 |
| LTN154X5-L02 | Samsung | 15.4 | 1280×800 |
| B140XTN02.4 | AUO | 14.0 | 1366×768 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP156WH4-TPA1 | LG Display | 15.6 | 1366×768 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| LQ133T1JW01 | SHARP | 13.3 | 2560×1440 |
| LQ141X1LH03 | SHARP | 14.1 | 1024×768 |
| LTN150PF-L04 | Samsung | 15.0 | 1400×1050 |
| LTN160AT03-002 | Samsung | 16.0 | 1366×768 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
