| PartNumber | LTN170CT08-L01 |
| Brand | Samsung |
| Size | 17.0 |
| Application | NBPC |
| Resolution | 1920(RGB)×1200 , WUXGA |
| Composition | LCM |
| Brightness | 280 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | RGB LED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTN170CT08-L01 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 367.2×229.5 mm |
| Outline | 382.2×247.5×7 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare (Haze 40%), Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE1931110% |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | RGB LEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
