| PartNumber | LTP400WQ-F01 |
| Brand | Samsung |
| Size | 4.0 |
| Application | PND |
| Resolution | 480(RGB)×272 , WQVGA |
| Composition | LCM |
| Brightness | 180 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SAMSUNG |
| Panel Model | LTP400WQ-F01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 4.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 87.84×49.776 mm |
| Outline | 98.3×62.6 mm |
| Surface | |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Viewing Angle | 65/65/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1PWLED |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| Input Voltage | 2.5/5.0V (Typ.)(VDD/AVDD) |
