| PartNumber | M080AWP9 R0 |
| Brand | IVO |
| Size | 8.0 |
| Application | Automotive Display |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 700:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | Parallel |
| Model | M080AWP9 R0 |
| Diagonal Size | 8.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×480 [WVGA] 115PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 175.2(H)×105.12(V) mm |
| Outline Dim. | 186.5(H)×117.22(V) ×6.65(D) mm |
| Bezel Area | 177.4(H)×107.32(V) mm |
| Treatment | Antiglare |
| Luminance | 750 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 13 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K 70% NTSC |
| Light Source | WLED [7S3P] , 30K hours , W/O Driver |
| Weight | 195/215g (Typ./Max.) |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| Power Supply | 3.3/10.6/22/-7.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
