| PartNumber | M125NWR3 R0 |
| Brand | IVO |
| Size | 12.5 |
| Application | NBPC |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | IVO |
| Panel Model | M125NWR3 R0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 12.5 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 275.59×154.94 mm |
| Outline | 290.5×180.9×2.85 mm |
| Shape Style | Slim (PCBA Flat, Depth ≤3.2mm) |
| Surface | Antiglare |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193150% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | eDP (2 Lanes), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| B125XW02 V0 | AUO | 12.5 | 1366×768 |
| HB125WX1-100 | BOE | 12.5 | 1366×768 |
| HB125WX1-200 | BOE | 12.5 | 1366×768 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LTN125AT02-301 | Samsung | 12.5 | 1366×768 |
| M125NWN1 R0 | IVO | 12.5 | 1366×768 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| M125NWR3 R0 | IVO | 12.5 | 1366×768 |
| NV125QUM-N81 | BOE | 12.5 | 3840×2160 |
| B140RW02 V2 | AUO | 14.0 | 1600×900 |
| B154EW02 V2 | AUO | 15.4 | 1280×800 |
| FLC31SVC6S-17 | Fujitsu | 12.1 | 800×600 |
| LP140WH1-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TPD1 | LG Display | 14.0 | 1366×768 |
| LP141WX5-TPP1 | LG Display | 14.1 | 1280×800 |
| LTD111EXDA | TOSHIBA | 11.1 | 1366×768 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
| NL6448AC33-10 | NLT | 10.4 | 640×480 |
