| PartNumber | M190PW01 V80K |
| Brand | AUO |
| Size | 19.0 |
| Application | Desktop Monitor |
| Resolution | 1440×900 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 11S4P WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Screen Size | 19.0 inch |
| Pixel Number | 1440(RGB)×900 (WXGA+) 89PPI |
| Active Area(mm) | 408.24 × 255.15 (H×V) |
| Bezel Area(mm) | 412.24 × 259.15 (H×V) |
| Luminance | 250 cd/m² (Typ.) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Good View at | - |
| Color Depth | 16.7M 72% NTSC |
| Mass | 1.52Kgs (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | M190PW01 V80K |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 428 × 278 × 10.8 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 3.5/1.5 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Desktop Monitor |
| Touchscreen | Without |
