| PartNumber | M236HJJ-P02 Rev.C4 |
| Brand | Innolux |
| Size | 23.6 |
| Application | Desktop Monitor |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Model | M236HJJ-P02 Rev.C4 |
| Diagonal Size | 23.6 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 1920(RGB)×1080 [FHD] 93PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 521.28(H)×293.22(V) mm |
| Outline Dim. | 534.28(H)×306.252(V) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 20/5 (Typ.)(Tr/Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | Super MVA, Normally Black, Transmissive |
| Plate Thickness | - |
| Transmittance | 4.8% (Typ.)(with Polarizer) |
| Support Color | 16.7M 72% NTSC |
| Light Source | No B/L |
| Weight | TBD |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-P02 | Innolux | 23.6 | 1920×1080 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
| V236H1-L01 | Innolux | 23.6 | 1920×1080 |
