| PartNumber | M238HCA-LCZ |
| Brand | Innolux |
| Size | 23.8 |
| Application | Desktop Monitor Gami |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 23.8 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 92PPI |
| Active Area | 527.04(H)×296.46(V) mm |
| Bezel Area | - |
| Luminance | 250 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Support Color | 16.7M 99% sRGB |
| Weight | 2.23/2.34Kgs (Typ./Max.) |
| Frame Rate | 60Hz |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | M238HCA-LCZ |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 535(H)×313(V) ×12.7(D) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 14 (Typ.)(G to G) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Light Source | WLED [4 strings] , 30K hours , W/O Driver |
| Designed For | Desktop Monitor Gaming |
| Touch Panel | Without |
