| PartNumber | LM238WF2-SSF1 |
| Brand | LG Display |
| Size | 23.8 |
| Application | DMPC |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | LM238WF2-SSF1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.8 inch |
| Display Mode | AH-IPS, Normally Black, Transmissive |
| Active Area | 527.04×296.46 mm |
| Outline | 535×313×13.2 mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| LM238WF1-SLE1 | LG Display | 23.8 | 1920×1080 |
| LM238WF1-SLK1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSF1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSK1 | LG Display | 23.8 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM238WQ1-SLA1 | LG Display | 23.8 | 2560×1440 |
| LM238WR1-SLA1 | LG Display | 23.8 | 3840×2160 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LM170E03-TLJ5 | LG Display | 17.0 | 1280×1024 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM215WF2-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM220WE1-TLD2 | LG Display | 22.0 | 1680×1050 |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LTM213U6-L02 | Samsung | 21.3 | 1600×1200 |
| LTM236FL01 | Samsung | 23.6 | 3840×2160 |
| M270H1-L01 | Innolux | 27.0 | 1920×1080 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
