| PartNumber | M238KCJ-L5B |
| Brand | Innolux |
| Size | 23.8 |
| Application | Desktop Monitor |
| Resolution | 2560×1440 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 23.8 inch |
| Pixel Format | 2560(RGB)×1440 [Quad-HD] 123PPI |
| Active Area | 525.696(H)×295.704(V) mm |
| Bezel Area | - |
| Luminance | 300 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Support Color | 16.7M 95% DCI-P3 |
| Weight | 2.40/2.52Kgs (Typ./Max.) |
| Frame Rate | 60Hz |
| Interface Type | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Power Supply | 10.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | M238KCJ-L5B |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 536.3(H)×313.7(V) ×14.9(D) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 8/7 (Typ.)(Tr/Td) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Light Source | WLED , 30K hours , W/O Driver |
| Designed For | Desktop Monitor |
| Touch Panel | Without |
