| PartNumber | M270HAN01.2 |
| Brand | AUO |
| Size | 27.0 |
| Application | Desktop Monitor |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 27.0 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 81PPI |
| Active Area | 597.888(H)×336.312(V) mm |
| Bezel Area | - |
| Luminance | 300 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Support Color | 16.7M 72% NTSC |
| Weight | 3.14Kgs (Typ.) |
| Frame Rate | 60Hz |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | M270HAN01.2 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 607.1(H)×354.1(V) ×13.4(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 14 (Typ.)(G to G) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Light Source | WLED [17S4P] , 30K hours , W/O Driver |
| Designed For | Desktop Monitor |
| Touch Panel | Without |
