| PartNumber | M270HTN02.2 CELL |
| Brand | AUO |
| Size | 27.0 |
| Application | Desktop Monitor Gaming |
| Resolution | 1920(RGB)×1080, FHD, 81PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | V-by-One |
| Panel Brand | AUO |
| Panel Size | 27.0" |
| Display Area | 597.6(W)×336.15(H) mm |
| Outline Size | 608.3(W)×349.3(H) ×1.5(D) mm |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Glass Depth | 0.50+0.50 mm |
| Display Colors | 16.7M 71% NTSC |
| Frequency | 144Hz |
| Driver IC | COF Built-in 6 source chips |
| Panel Weight | 665g (Typ.) |
| Signal Interface | V-by-One 8 lane , 40 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | M270HTN02.2 CELL |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 3.8/1.2 (Typ.)(Tr/Td) |
| Transmissivity | 5.3% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
| LM270WF1-TLD1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V1 | AUO | 27.0 | 1920×1080 |
