PartNumber | M280HKJ-L50 Rev.C3 |
Brand | Innolux |
Size | 28.0 |
Application | Desktop Monitor |
Resolution | 1920×1080 |
Composition | LCM, a-Si TFT-LCD |
Brightness | |
CR | 3000:1 |
Colors | 16.7M |
Backlight | 4 strings WLED , 40K hours , No Driver |
Interface | |
Manufacturer | Innolux |
Model Name | M280HKJ-L50 Rev.C3 |
Screen Size | 28.0 inch |
Screen Type | LCM, a-Si TFT-LCD |
Pixel Number | 1920(RGB)×1080 (FHD) 78PPI |
Arrangement | RGB Vertical Stripe |
Active Area(mm) | 620.928 × 341.28 (H×V) |
Outline(mm) | 648.9 × 396.4 × 15.3 (H×V×D) |
Bezel Area(mm) | 626.9 × 347.3 (H×V) |
Treatment | Antiglare (Haze 25%), Hard coating (3H) |
Luminance | 300 cd/m² (Typ.) |
Contrast Ratio | 3000 : 1 (Typ.) (TM) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Response | 20/5 (Typ.)(Tr/Td) ms |
Good View at | Symmetry |
Work Mode | MVA, Normally Black, Transmissive |
Color Depth | 16.7M 98% NTSC |
Mass | 2.73/2.87Kgs (Typ./Max.) |
Used for | Desktop Monitor |
Refresh Rate | 60Hz |
Touchscreen | Without |
Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
