| PartNumber | MCT-G320240DTCW-151N |
| Brand | TRULY |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 320×240 |
| Composition | CSTN-LCD , LCM |
| Brightness | |
| CR | 45:1 |
| Colors | Color |
| Backlight | CCFL |
| Interface | Parallel |
| Diagonal Size | 5.7 inch |
| Pixel Format | 320(RGB)×240 [QVGA] 70PPI |
| Active Area | 115.18(H)×86.38(V) mm |
| Bezel Area | 119.18(H)×90.38(V) mm |
| Luminance | 220 cd/m² (Typ.) |
| View Direction | - |
| Viewing Angle | 50/50/55/40 (Typ.)(CR≥10) |
| Support Color | Color |
| Weight | - |
| Frame Rate | - |
| Interface Type | Parallel Data (1ch, 8-bit) , 16 pins Connector |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C |
| Model | MCT-G320240DTCW-151N |
| Type | CSTN-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 158.5(H)×109(V) ×9.2(D) mm |
| Treatment | - |
| Contrast Ratio | 45:1 (Typ.) (TM) |
| Response Time | 215/110 (Typ.)(Tr/Td) |
| Operating Mode | STN, Normally Black, Transmissive |
| Light Source | CCFL [1 pcs] , 15K hours , W/O Driver |
| Designed For | Industrial |
| Touch Panel | Without |
